A101J1AQ004
Manufacturer:
TE Connectivity
Mfr.Part #:
A101J1AQ004
Datasheet:
Description:
Rocker Switches Through Hole SPDT ON - ON Illuminated Concave (Standard V) Current Rating:5 A
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 28 V |
| Length | 12.7 mm |
| Width | 9.27 mm |
| Termination | PC Pins, Quick Connect |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -30 °C |
| Voltage Rating (AC) | 120 V |
| Height | 9.4 mm |
| Circuit Type | SPDT |
| Packaging | Bulk |
| Lead Free | Lead Free |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Silver |
| Type | Switch |
| Current Rating | 5 A |
| Max Current Rating | 5 A |
| Max Voltage Rating (DC) | 28 V |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 4 days ago) |
| Color | Black |
| ELV | Compliant |
| Throw Configuration | SPDT |
| Contact Resistance | 10 mΩ |
| Max Voltage Rating (AC) | 250 V |
| Switch Function | ON - ON |
| Illumination Type | Illuminated |
| Electrical Life | 6 kcycles |
| Actuator Material | Phenolic |
| Contact Current Rating | 5 A |
| Actuator Type | Concave (Standard V) |
| Termination Style | PC Pin |
| VDE Tested | No |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 4 days ago) |
Stock: 19
Distributors
pcbx
pcbxUnit Price$5.33003
Ext.Price$5.33003
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $5.33003 | $5.33003 |
| 10 | $4.36191 | $43.61910 |
| 25 | $4.27383 | $106.84575 |
| 50 | $4.18749 | $209.37450 |
